Perkins Diesel Generator Set
Gutai Machinery is a professional leader China perkins diesel generator set manufacturer with high quality and reasonable price. Perkins diesel generator sets are suitable for various application scenarios, including emergency, standby, main and continuous power generation needs.
Gutai Machinery is a leading China perkins diesel generator set manufacturer. Perkins diesel generator set is one of the diesel generator equipment, which is a generator equipment produced by Perkins. Perkins diesel generator set uses original imported engines. These engines use the latest European and American technology and high-strength wear-resistant materials to ensure first-class quality.
Perkins diesel generator sets are suitable for various application scenarios, including emergency, standby, main and continuous power generation needs. Its power range is wide, from 7KW to 1811KW, and the speed range is from 1500rpm to 2600rpm. The standard unit has a three-phase four-wire output, the output voltage is 380V/220V, the frequency is 50HZ/60HZ, the power factor is 0.8 lag, and the protection performance meets NEMA1 and IP22 standards.
Product Parameter
| Perkins diesel generator set 60Hz 1800rpm | |||||||||
| Model | Unit power | esel engine mode | Silent type size | weight | |||||
| Main | standby | Silent type | Open type | Silent type | Open type | ||||
|
|
KW | KVA | KW | KVA | mm | mm | kg | kg | |
| XGT12 | 9 | 11 | 9.9 | 12 | 403D-11G | 1800X880X1050 | 1360X670X1100 | 670 | 420 |
| XGT-17 | 12 | 15 | 13.2 | 17 |
403D-15G |
1900X880X1080 | 1350X600X1100 | 670 | 420 |
| XGT-18 | 13 | 16 | 14.3 | 18 | 403A15G2 | 1900X880X1080 | 1350X600X1100 | 680 | 420 |
| XGT-26 | 19 | 24 | 20.9 | 26 | 404D-22G | 1970X880X1130 | 1420X600X1120 | 680 | 535 |
| XGT-34 | 25 | 31 | 27.5 | 34 | 404D-22TG | 1970X880X1130 | 1420X600X1121 | 695 | 536 |
| XGT-40 | 28 | 35 | 30.8 | 39 | 1103A-33G | 2280X1000X1200 | 1700X760X1150 | 796 | 540 |
| XGT-60 | 42 | 53 | 46.2 | 58 | 1103A-33TG1 | 2280X1000X1200 | 1700X760X1150 | 796 | 540 |
| XGT-74 | 54 | 68 | 59 | 74 | 1103A-33TG2 | 2400X1000X1300 | 1750X700X1200 | 999 | 740 |
| XGT-83 | 60 | 75 | 66 | 83 | 1104A-44TG1 | 2500X1000X1300 | 1850X700X1300 | 1064 | 920 |
| XGT-100 | 72 | 90 | 79.2 | 99 | 1104A-44TG2 | 2550X100X1300 | 1850X700X1300 | 1179 | 920 |
| XGT-100 | 72 | 90 | 79.2 | 99 | 1104C-44TAG1 | 2850X1100X1600 | 1900X700X1450 | 1257 | 980 |
| XGT-124 | 90 | 113 | 99 | 124 | 1104C-44TAG2 | 2850X1100X1600 | 1900X700X1450 | 1357 | 910 |
| XGT-186 | 135 | 169 | 148.5 | 186 | 1106A-70TAG2 | 3300X1100X1600 | 2100X730X1450 | 1965 | 1550 |
| XGT-220 | 160 | 200 | 176 | 220 |
1106A-70TAG3 |
3350X1100X1600 | 2100X730X1450 | 2059 | 1610 |
| XGT-250 | 180 | 225 | 198 | 248 | 1206AE70TTAG1 | 3450X1250X1850 | 2250X850X1500 | 3370 | 1850 |
| XGT-440 | 320 | 400 | 352 | 440 | 2206A-E13TAG5 | 4200X1450X2200 | 3100X1130X2090 | 4533 | 3300 |
| XGT-481 | 350 | 438 | 385 | 481 | 2206A-E13TAG6 | 4300X1450X2200 | 3100X1130X2090 | 4633 | 3400 |
|
XGT-550 |
400 | 500 | 440 | 550 | 2506A-E15TAG3 | 4500X1700X2250 | 3430X1130X2090 | 5076 | 3800 |
| XGT620 | 450 | 563 | 495 | 619 | 2506A-E15TAG4 | 4500X1700X2250 | 3430X1130X2090 | 5236 | 4000 |
| XGT-688 | 500 | 625 | 550 | 688 | 2806A-E18TAG1A | 4650X1900X2450 | 3500X1160X2092 | 6000 | 4350 |
| XGT-743 | 540 | 675 | 594 | 743 | 2806A-E18TAG3 | 4650X1900X2450 | 3500X1160X2090 | 6135 | 4200 |
| XGT-825 | 600 | 750 | 660 | 825 | 4006-23TAG2A | 20GP | 3990X1710X2190 | 7550 | 5380 |
| XGT-1100 | 800 | 1000 | 880 | 1100 | 4008TAG2 | 20GP | 4750X2050X2430 | 8600 | 7400 |
| XGT-1375 | 1000 | 1250 | 1100 | 1375 | 4012-46TWG2A | 40HC | 4750X2050X2500 | 11600 | 11600 |
| XGT-1650 | 1200 | 1500 | 1320 | 1650 | 4012-46TAG2A | 40HC | 4980X2200X2520 | 12100 | 12100 |
The product features of Perkins diesel generator set are as follows:
1. Compact structure: save space, easy to install and transport.
2. Stable and reliable performance: ensure long-term stable operation.
3. Easy maintenance: the operation and use technology is gradually familiar to Chinese customers, reducing maintenance costs.
Meet the Euro III environmental emission standard: low exhaust gas pollution, in line with environmental protection requirements
