Weifang Diesel Generator Set
  • Weifang Diesel Generator SetWeifang Diesel Generator Set

Weifang Diesel Generator Set

Gutai Machinery is a professional leader China weifang diesel generator set manufacturer with high quality and reasonable price. Weifang diesel generator sets are widely used in shipping, national defense, communications, petroleum, medical treatment, mining, field rescue, agriculture and animal husbandry, backup power supply and other fields.

Gutai Machinery is China manufacturer and supplier who mainly produces weifang diesel generator set with many years of experience. Weifang diesel generator set is a device used for power generation. Weifang diesel generator set is famous for its stable quality, low price and good quality. It is produced with advanced technology and has the characteristics of low fuel consumption, low emissions and low noise. Weifang diesel generator set is widely used in the fields of ships, national defense, communications, petroleum, medical treatment, mining, field rescue, agriculture and animal husbandry, and backup power supply.


Weifang diesel generator set product advantages:

High reliability: Weichai generator set adopts diesel engine independently developed by Weichai Group. After a long period of market verification, it can ensure long-term normal operation.

Stable power supply: Weichai generator set can provide stable power supply and uninterrupted power supply to ensure long-term continuous use of users.


Fuel economy

Efficient fuel injection technology: Weichai generator set adopts scientific fuel injection technology, which has the characteristics of high efficiency and low fuel consumption, and can effectively reduce operating costs3.

Low fuel consumption rate: The optimized diesel engine has a low fuel consumption rate, which saves money for users.


Environmental protection characteristics

Low noise design: Weichai generator set adopts scientific noise reduction technology, which effectively reduces the noise level of the generator set and provides users with a quiet working environment.

Environmental protection requirements: Weichai generator sets meet environmental protection requirements and reduce pollution to the environment.


Weifang diesel generator set 30KW

1、 Technical parameters of generator set
Model XGT-30 manufacturer Quanzhou Gutai Machinery Equipment Co., Ltd
Voltage recovery time ≤1S Steady state frequency regulation ≤ 1%
rated voltage 400V/230V Frequency stabilization time ≤3S
Rated frequency 50HZ Transient frequency adjustment rate ≤1%
Electric system three-phase four-wire system Volatility rate ≤1%
Rated current 54A Reference weight 750Kg
Power factor 0.8 (lag) Rotational speed 1500r/min
Steady-state voltage regulation rate ≤±1% Reference external dimensions
(Length * Width * Height)
1650*680*1150(mm)
Transient voltage regulation rate -15%~+18% Cooling method Self closing water cycle
Fuel grade (Standard) 0 # light diesel oil (at room temperature) Noise (LP7M) Normal configuration ≤ 117dB (A)
2、 Technical parameters of diesel engine
Origin (brand) Weifang (Huachi) manufacturer Weifang Huachi Diesel Engine Co., Ltd
output power 33KW Model ZH4100D
Number of cylinders 4 Compression ratio 17.0:1
Piston aperture/piston stroke 100mm/115mm Start mode Electric start
Minimum fuel consumption rate ≤215g/kw.h Starting power supply DC 24V
Exhaust volume 3.61L Speed Control electronic speed control
fuel system PT pump direct injection Air intake system turbocharging
Diesel engine type 4-cylinder straight, 4-stroke Emission limits for pollutants Non Road Country II
3、 Technical parameters of generator
brand Min Dong Kang Da model STC-30
Excitation method Brush, excitation, self cooling protection grade IP22
Pressure regulating system AVR automatic voltage regulation Short term overcurrent 3-5 Ie not less than 5S
Insulation level H Overload capacity 1.5Ie not less than 2 minutes
Winding material All copper wire winding Phase number and connection method three-phase four-wire system
System function: The unit is equipped with an LCD display screen, self starting and automatic shutdown function, intelligent control system, with low oil pressure, high water temperature, overspeed, and low
Protection functions for speed, overload, and low voltage storage.


Weifang diesel generator set 100KW

1、 Technical parameters of generator set
Model XGT-100 manufacturer Quanzhou Gutai Machinery Equipment Co., Ltd
Voltage recovery time ≤1S Steady state frequency regulation ≤1%
rated voltage 400V/230V Frequency stabilization time ≤3S
Rated frequency 50HZ Transient frequency adjustment rate ≤1%
Electric system three-phase four-wire system Volatility rate ≤1%
Rated current 180A Reference weight 950Kg
Power factor 0.8 (lag) Rotational speed 1500r/min
Steady-state voltage regulation rate ≤±1% Reference external dimensions
(Length * Width * Height)
2350*760*1300(mm)
Transient voltage regulation rate -15%~+18% Cooling method Boosting intercooling
Fuel grade (Standard) 0 # light diesel oil (at room temperature) Noise (LP7M) Normal configuration ≤ 117dB (A)
2、 Technical parameters of diesel engine
Origin (brand) Shandong (Huachi) manufacturer Weifang Huachi Diesel Engine Co., Ltd
output power 121KW Model HC6105AZLD
Number of cylinders 6 Compression ratio 16.5:1
Piston aperture/piston stroke 105mm/130mm Start mode Electric start
Minimum fuel consumption rate ≤218g/kw.h Starting power supply DC 24V
Exhaust volume 6.75L Speed Control electronic speed control
fuel system PT pump direct injection Air intake system turbocharging
Diesel engine type 6-cylinder straight, 4-stroke Emission limits for pollutants
price
Non Road Country II
3、 Technical parameters of generator
Brand Shanghai Lichun Model LCW-100-4(100KW)
Excitation method Brushless, excitation, self cooling protection grade IP22
Voltage regulation system AVR automatic voltage regulation Short term overcurrent 3-5 Ie not less than 5S
Insulation level H Overload capacity 1.5Ie not less than 2 minutes
Winding material All copper wire winding Phase number and connection method three-phase four-wire system


Weifang diesel generator set 50KW



Hot Tags: Weifang Diesel Generator Set, China, Manufacturer, Supplier, Factory
